GOWE Automatic Wire Stripping and Cutting Machine for 10 Square Wires - Computerized Wire Stripper for Electrical Work, DIY Projects, and Home Repairs

Features

Automatic strip wire machine/skinning cutting wire machine/computer strip wire machine 10 square/ The product function characteristics/ Electromechanical, microcomputer for the integration of the fully automatic computer wire stripping machine is a kind of the introduction of Japan, Taiwan and other advanced technology of automatic numerical control equipment./

Widely used in electronic industry, automobile industry, electrical appliances, motors, lamps, toys and other kinds of wiring harness processing products.Optimum strip wire with PVC, teflon wire, glass, etc.Our products is to use LCD screen man-machine dialogue mode, has a beautiful appearance, simple operation, convenient maintenance, stable performance, fast speed, high precision characteristics./

Wire length can be set arbitrary, thread and tail line parameters can also be modified according to customer requirements, can strip wire of different thickness, also have to row of shear line, the high tension line casing, and other functions/ Product technical parameters/ Product model SWT508 - JE/ Electricity source, AC 110 v / 220 v / 50/60 hz/

Installation dimensions 390 x350x255/ Display LCD liquid crystal display interface in both Chinese and English/ Weight 32 (KG)/ Work rate 300 (W)/ Cutting length 1-9999 - mm/ Cutting tolerance (+ / - 0.002 x 0.2 L) mm/ Error can be fixed/ Stripping length thread on a scale of 0-80, 0-80 - mm line end/

Intermediate cutting ten peel/ Cutting line core section 0.1-10 was (AWG8 # - AWG32 #)/ Pipe diameter diameter 12/ Optimum strip wire PVC/teflon/silica gel line /. Glass fiber wire, etc/ Import Bai Gang blade material hard tungsten steel (optional)/ Peel linear velocity (per hour) L = 100 mm, 3000-8000 PCS/h (high yield)/ Driving mode four-wheel drive/
